II Series Safe

Professionals safes

Series of safes of new design and certified according to UNE EN-1143-1 Grade II standard and certified against fire according to UNE EN-15659 Grade LFS 30 P (*), i.e. for 30 min. without exceeding 170 º C inside.

Perfect for home or business.

They are offered in 6 different versions in terms of type of closure.

* Currently the UNE EN-15659 Grade LFS 30 P certification is only available with the AM-25 size, soon for the other sizes.

Certificate

UNE EN-1143-1 GRADE II

UNE EN-15659 GRADE LFS 30P

See models

Specifications

  • 50-mm thick door and body.
  • Bolt-hole for anchoring to floor and wall, with M-12 (50 kN) anchorage included.
  • Drill-proof armour plating.
  • Relock in the event of attack.
  • Handle operation with 12 Ø25 mm revolving bolts: 4+4 at the sides, 2 at the top and 2 at the bottom.
  • Models AM-8, AM-85, AM.9, AM-95 and AM-10, have 16 Ø25mm bolts: 5+5 at the sides, 3 at the top and 3 at the bottom.
  • El model AM-1 disposa de 8 pestells de Ø 25mm: 2 + 2 laterals, 2 superiors i 2 inferiors.
  • Tip-proof, height-adjustable shelves for all sizes except AM-1.
  • Passive fire protection by means of an intumescent fire seal in the door.
  • Colour Ral Design 000 35 00.

Related documents

Models

Lever lockMechanicalElectronics and delay2 Key LocksMechanical and lever lockElectronic, delay and lever lockDimensions caixes
Exterior Measurements
(mm.)		Interior Measurements
(mm.)		Measures Use
(mm.)		Internal VolumeWeightBolts NumberNumber of Shelves
ABC
AM1LAM1MAM1EAM1LE3504403502503401953957608251711581
AM2LAM2MAM2EAM2LLAM2LMAM2LE50045045040035029549587084541190122
AM25LAM25MAM25EAM25LLAM25LMAM25LE5005505504004503955951070104571250122
AM3LAM3MAM3EAM3LLAM3LMAM3LE6505505505504503955951070104598305122
AM4LAM4MAM4EAM4LLAM4LMAM4LE80055055070045039559510701045124360123
AM45LAM45MAM45EAM45LLAM45LMAM45LE80070055070060039559512201345166425123
AM5LAM5MAM5EAM5LLAM5LMAM5LE95055055085045039559510701045151410123
AM6LAM6MAM6EAM6LLAM6LMAM6LE1100550550100045039559510701045178465124
AM65LAM65MAM65EAM65LLAM65LMAM65LE1100700550100060039559512201345237550124
AM7LAM7MAM7EAM7LLAM7LMAM7LE1250550550115045039559510701045204520125
AM75LAM75MAM75EAM75LLAM75LMAM75LE1250700550115060039559512201345273610125
AM8LAM8MAM8EAM8LLAM8LMAM8LE1400650650130055049569512201245354715165
AM85LAM85MAM85EAM85LLAM85LMAM85LE1400800650130070049569514201545450820165
AM9LAM9MAM9EAM9LLAM9LMAM9LE1550800750145070059579515201545604980166
AM95LAM95MAM95EAm95LLAM95LMAM95LE1550800650145070049569514201545502895166
AM10LAM10MAM10EAM10LLAM10LMAM10LE1700800650160070049569514201545554970166
Left opening
